Hastelloy C22 flanges are particularly effective in environments containing strong oxidizers such as ferric and cupric chlorides, chlorine, and nitric acid mixtures. They provide exceptional resistance to localized corrosion such as pitting and crevice corrosion, making them suitable for use in scrubbers, reactors, and pressure vessels.
Hastelloy C2000 flanges are an advanced nickel-chromium-molybdenum-copper alloy designed for extreme chemical environments. Their unique composition makes them resistant to both oxidizing and non-oxidizing chemicals. These flanges are ideal for modern chemical plants where multiple aggressive media are present in one process.
Hastelloy B2 flanges are formulated for excellent resistance to pure hydrochloric acid and other strongly reducing media. They are highly resistant to stress corrosion cracking and show excellent performance in a wide range of non-oxidizing acid environments, making them a top choice in chemical transfer and acid regeneration systems.
Hastelloy B3 flanges are the next generation of B-series alloys, offering improved thermal stability and resistance to spontaneous aging. This makes them suitable for more demanding applications where temperature fluctuation and aggressive chemical exposure are constant. B3 flanges also resist pitting and hydrogen embrittlement better than earlier versions.
Specification of Hastelloy C22 C2000 B2 B3 Flanges
| Specification | Hastelloy C22 | Hastelloy C2000 | Hastelloy B2 | Hastelloy B3 |
|---|---|---|---|---|
| Standard Specification | ASTM B564, ASME B16.5 | ASTM B564, ASME B16.5 | ASTM B564, ASME B16.5 | ASTM B564, ASME B16.5 |
| Material Composition | Ni-Cr-Mo-Fe-W | Ni-Cr-Mo-Cu | Ni-Mo | Ni-Mo |
| Corrosion Resistance | Excellent in oxidizing & reducing | Excellent in mixed chemical media | Excellent in reducing environments | Improved thermal & chemical resistance |
| Density | 8.69 g/cm³ | 8.62 g/cm³ | 9.24 g/cm³ | 9.22 g/cm³ |
| Melting Range | 1325–1370 °C | 1350–1390 °C | 1370–1418 °C | 1370–1418 °C |
| Tensile Strength (min) | 690 MPa (100 ksi) | 760 MPa (110 ksi) | 760 MPa (110 ksi) | 760 MPa (110 ksi) |
| Yield Strength (0.2% min) | 283 MPa (41 ksi) | 350 MPa (51 ksi) | 310 MPa (45 ksi) | 310 MPa (45 ksi) |
| Elongation (%) | 45% | 40% | 40% | 40% |
| Flange Types Available | Weld Neck, Blind, Slip-On, Socket Weld, Threaded, Lap Joint | Same as C22 | Same as C22 | Same as C22 |
| Pressure Classes | 150, 300, 600, 900, 1500, 2500 | 150, 300, 600, 900, 1500, 2500 | 150, 300, 600, 900, 1500, 2500 | 150, 300, 600, 900, 1500, 2500 |
| Applications | Chemical processing, pollution control, pulp & paper | Acid production, power plants, chemical reactors | Hydrochloric acid, pickling, waste treatment | Pharmaceuticals, organic chemicals, heat exchangers |
All Hastelloy alloy flanges are manufactured with precision and undergo strict quality testing to ensure dimensional accuracy and performance reliability. Whether used in high-pressure pipelines or critical chemical reactors, these flanges provide unmatched safety and durability in corrosive environments.
Chemical Composition of Hastelloy C22 C2000 B2 B3 Flanges
| Element | Hastelloy C22 | Hastelloy C2000 | Hastelloy B2 | Hastelloy B3 |
|---|---|---|---|---|
| Nickel (Ni) | Balance | Balance | Balance | Balance |
| Chromium (Cr) | 20.0 – 22.5 | 22.0 – 24.0 | ≤ 1.0 | ≤ 1.0 |
| Molybdenum (Mo) | 12.5 – 14.5 | 15.0 – 17.0 | 26.0 – 30.0 | 27.0 – 32.0 |
| Iron (Fe) | 2.0 – 6.0 | 2.0 – 7.0 | 2.0 max | 1.5 – 3.0 |
| Cobalt (Co) | 2.5 max | 2.0 max | 1.0 max | 3.0 max |
| Tungsten (W) | 2.5 – 3.5 | — | — | — |
| Copper (Cu) | — | 1.3 – 1.9 | 0.5 max | 0.2 max |
| Carbon (C) | 0.015 max | 0.02 max | 0.02 max | 0.01 max |
| Silicon (Si) | 0.08 max | 0.08 max | 0.10 max | 0.10 max |
| Manganese (Mn) | 0.5 max | 0.5 max | 1.0 max | 1.5 max |
| Phosphorus (P) | 0.02 max | 0.025 max | 0.04 max | 0.02 max |
| Sulfur (S) | 0.02 max | 0.01 max | 0.03 max | 0.01 max |
With a proven track record as a Hastelloy C22 C2000 B2 B3 Flanges exporter in over 30 countries, Sumer Metal Industries ensures global availability, third-party inspection support, and client-specific customization. Our wide export network combined with strict quality standards has made us a preferred choice for SS 202 tubing worldwide.
Specification of Hastelloy C22 C2000 B2 B3 Flanges
| Specification | Hastelloy C22 | Hastelloy C2000 | Hastelloy B2 | Hastelloy B3 |
|---|---|---|---|---|
| Standard Specification | ASTM B564, ASME B16.5 | ASTM B564, ASME B16.5 | ASTM B564, ASME B16.5 | ASTM B564, ASME B16.5 |
| Material Composition | Ni-Cr-Mo-Fe-W | Ni-Cr-Mo-Cu | Ni-Mo | Ni-Mo |
| Corrosion Resistance | Excellent in oxidizing & reducing | Excellent in mixed chemical media | Excellent in reducing environments | Improved thermal & chemical resistance |
| Density | 8.69 g/cm³ | 8.62 g/cm³ | 9.24 g/cm³ | 9.22 g/cm³ |
| Melting Range | 1325–1370 °C | 1350–1390 °C | 1370–1418 °C | 1370–1418 °C |
| Tensile Strength (min) | 690 MPa (100 ksi) | 760 MPa (110 ksi) | 760 MPa (110 ksi) | 760 MPa (110 ksi) |
| Yield Strength (0.2% min) | 283 MPa (41 ksi) | 350 MPa (51 ksi) | 310 MPa (45 ksi) | 310 MPa (45 ksi) |
| Elongation (%) | 45% | 40% | 40% | 40% |
| Flange Types Available | Weld Neck, Blind, Slip-On, Socket Weld, Threaded, Lap Joint | Same as C22 | Same as C22 | Same as C22 |
| Pressure Classes | 150, 300, 600, 900, 1500, 2500 | 150, 300, 600, 900, 1500, 2500 | 150, 300, 600, 900, 1500, 2500 | 150, 300, 600, 900, 1500, 2500 |
| Applications | Chemical processing, pollution control, pulp & paper | Acid production, power plants, chemical reactors | Hydrochloric acid, pickling, waste treatment | Pharmaceuticals, organic chemicals, heat exchangers |
🏭 Industry & Application
- ✅ SS 202 Capillary Tubes for Medical Industry
- ✅ SS 202 Capillary Tubes for Chemical Processing
- ✅ SS 202 Tubes for Instrumentation Lines
- ✅ Hastelloy C22 C2000 B2 B3 Flanges for Gas & Liquid Flow
- ✅ SS 202 Tubes for Heat Exchangers
❓ Frequently Asked Questions (FAQs)
Q1:What are Hastelloy flanges used for?
Hastelloy flanges are used in highly corrosive environments such as chemical processing, marine, pharmaceuticals, power plants, and wastewater treatment. Each grade (C22, C2000, B2, B3) is engineered for specific corrosion resistance and performance.
Q2: Are Hastelloy flanges resistant to seawater?
Yes, particularly Hastelloy C22 and C2000 flanges exhibit good resistance to seawater and marine atmospheres, but material selection should still consider exact chemical exposure and temperature.
Q3:What sizes and pressure classes are available?
Sizes typically range from ½" to 24" (larger on request) with pressure classes including 150, 300, 600, 900, 1500, and 2500 as per ASME standards.
