Inconel 600 Capillary Tubes,Inconal 600 Capillary Tube Manufacturer,Inconal 600 Capillary Tube Supplier,Inconal 600 Capillary Tube Exporter,Inconal 600 Precision Tubing,Inconal 600 Small Diameter Tube ,Inconal 600 Instrumentation Tubes
Sumer Metal Industries Private Limited is a reputed manufacturer, supplier, and exporter of Inconel 600 capillary tubes (UNS N06600), serving clients across Oman, Qatar, Saudi Arabia, the UAE, Kuwait, Spain, Germany, the USA, Canada, and many African regions. Known for precision engineering, they deliver customized capillary tubes meeting international standards. Their exports are supported by quality documentation—mill test certificates and inspection reports—aligned with ASTM, ASME, DIN, ISO, and EN standards.
Leveraging advanced manufacturing capabilities, Sumer Metal Industries offers OD sizes from approximately 0.3 mm up to 12 mm or more, with wall thicknesses ranging typically from around 0.08 mm to 0.2 mm, customizable per client specifications Surface finishing options include bright annealed, pickled, polished, electropolished, ensuring the tubes are ideal for high-purity and instrumentation applications
Inconel 600 capillary tubes are widely used in thermocouple protection, instrumentation, chemical processing, heat treatment, power generation, and nuclear systems due to their outstanding high-temperature strength, oxidation, and corrosion resistance The alloy’s stability in extreme environments makes it a top choice across diverse industrial applications.
Sumer Metal Industries ensures that each batch of capillary tubes is subjected to rigorous quality control, including hydrostatic testing, eddy current testing, and dimensional verification. The tubes are available in both seamless and welded formats, with custom sizing available on request. Their production process guarantees smooth internal surfaces that minimize friction and fluid resistance, a crucial factor in maintaining accuracy in flow-based systems.
Specification of Inconel 600 Capillary Tubes
| Property | Specification |
|---|---|
| Material Grade | Inconel 600 (UNS N06600) |
| Standard | ASTM B163 / B167 / B516 / B517 |
| Chemical Composition | |
| - Nickel (Ni) | ≥ 72.0% |
| - Chromium (Cr) | 14.0 – 17.0% |
| - Iron (Fe) | 6.0 – 10.0% |
| - Carbon (C) | ≤ 0.15% |
| - Manganese (Mn) | ≤ 1.0% |
| - Silicon (Si) | ≤ 0.5% |
| - Sulfur (S) | ≤ 0.015% |
| Outer Diameter (OD) | 0.25 mm to 12.7 mm (custom sizes available) |
| Wall Thickness | 0.05 mm to 1.0 mm |
| Length | Coil form: up to 6,000 meters Straight lengths: up to 6 meters |
| Surface Finish | Bright annealed, pickled, or polished |
| Tensile Strength | ≥ 550 MPa |
| Yield Strength (0.2% Offset) | ≥ 240 MPa |
| Elongation | ≥ 30% |
| Hardness | ≤ 95 HRB |
| Density | 8.47 g/cm³ |
| Melting Point | 1354–1413°C |
| Corrosion Resistance | Excellent in high-temp and corrosive environments |
| Form | Coiled / Straight / U-Bent |
| Applications | Thermocouple protection, instrumentation, nuclear reactors, chemical processing, aerospace |
With a well-established export network, Sumer Metal Industries supplies Inconel 600 Capillary Tubes to various international markets, including Oman, Qatar, Saudi Arabia, UAE, Kuwait, Spain, Germany, USA, Canada, and numerous regions across Africa. Their ability to meet customized demands and deliver on tight lead times has positioned them as a preferred vendor in the global supply chain for nickel alloy tubing.
Chemical Composition of Inconel 600 Capillary Tubes
| Element | Symbol | Composition (% by Weight) |
|---|---|---|
| Nickel | Ni | ≥ 72.0 |
| Chromium | Cr | 14.0 – 17.0 |
| Iron | Fe | 6.0 – 10.0 (Balance*) |
| Carbon | C | ≤ 0.15 |
| Manganese | Mn | ≤ 1.00 |
| Silicon | Si | ≤ 0.50 |
| Sulfur | S | ≤ 0.015 |
| Copper | Cu | ≤ 0.50 |
| Aluminum | Al | ≤ 0.30 |
| Titanium | Ti | ≤ 0.30 |
With a proven track record as a Inconel 600 Capillary Tubes exporter in over 30 countries, Sumer Metal Industries ensures global availability, third-party inspection support, and client-specific customization. Our wide export network combined with strict quality standards has made us a preferred choice forNickel 20 tubing worldwide.
Specification of Inconel 600 Capillary Tubes
| Property | Specification |
|---|---|
| Material Grade | Inconel 600 (UNS N06600) |
| Standard | ASTM B163 / B167 / B516 / B517 |
| Chemical Composition | |
| - Nickel (Ni) | ≥ 72.0% |
| - Chromium (Cr) | 14.0 – 17.0% |
| - Iron (Fe) | 6.0 – 10.0% |
| - Carbon (C) | ≤ 0.15% |
| - Manganese (Mn) | ≤ 1.0% |
| - Silicon (Si) | ≤ 0.5% |
| - Sulfur (S) | ≤ 0.015% |
| Outer Diameter (OD) | 0.25 mm to 12.7 mm (custom sizes available) |
| Wall Thickness | 0.05 mm to 1.0 mm |
| Length | Coil form: up to 6,000 meters Straight lengths: up to 6 meters |
| Surface Finish | Bright annealed, pickled, or polished |
| Tensile Strength | ≥ 550 MPa |
| Yield Strength (0.2% Offset) | ≥ 240 MPa |
| Elongation | ≥ 30% |
| Hardness | ≤ 95 HRB |
| Density | 8.47 g/cm³ |
| Melting Point | 1354–1413°C |
| Corrosion Resistance | Excellent in high-temp and corrosive environments |
| Form | Coiled / Straight / U-Bent |
| Applications | Thermocouple protection, instrumentation, nuclear reactors, chemical processing, aerospace |
🏭 Industry & Application
- ✅ SS 202 Capillary Tubes for Medical Industry
- ✅ SS 202 Capillary Tubes for Chemical Processing
- ✅ SS 202 Tubes for Instrumentation Lines
- ✅ Inconel 600 Capillary Tubes for Gas & Liquid Flow
- ✅ SS 202 Tubes for Heat Exchangers
❓ Frequently Asked Questions (FAQs)
Q1: What export regions does Sumer Metal Industries cover?
They export Inconel 600 capillary tubes to Oman, Qatar, Saudi Arabia, the UAE, Kuwait, Spain, Germany, the USA, Canada, and regions across Africa.
Q2:What sizes and finishes are available?
They offer OD ranges approximately 0.3–12 mm, wall thicknesses around 0.08–0.2 mm, with finishing options including bright annealed, pickled, polished, and electropolished.
Q3:What are the typical mechanical properties of Inconel 600 capillary tubes?
In the annealed condition, these include tensile strength of ~550–655 MPa, yield strength around 310 MPa, elongation of ~30–40%, density ~8.47 g/cm³, melting point ~1413 °C.
