Sumer Metal Industries Private Limited manufactures premium Inconel 800, 800H and 800HT condenser tubes engineered for long-term, reliable service in demanding thermal and corrosive environments. Our production lines deliver both seamless and welded tubing with tight dimensional tolerances, full heat-number traceability and options for bespoke finishes — ensuring compatibility with EPC, OEM and fabricator requirements across the power, petrochemical and desalination sectors.
The Inconel 800 family (UNS N08800, N08810 and N08811) combines high nickel and chromium with iron to provide an excellent balance of oxidation and carburization resistance at elevated temperatures. Alloy 800 is typically selected for general high-temperature service, 800H for enhanced creep resistance due to controlled carbon content, and 800HT when higher temperature strength and improved creep-rupture properties are required for prolonged elevated-temperature exposure.
Our condenser tubes are widely used in shell-and-tube condensers, process heat exchangers, steam condensers, and seawater-cooled systems where cyclic thermal loads, chloride-bearing waters and occasional thermal shocks are common. The alloy’s good fabricability and stable mechanical properties at temperature make it a reliable choice where both corrosion resistance and mechanical integrity are priorities.
Sumer Metal Industries exports these Inconel tubes to strategic markets including Oman, Qatar, Saudi Arabia, the United Arab Emirates, Kuwait, Spain, Germany, the United States, Canada and several regions across Africa. Every export shipment is prepared with appropriate packing for ocean or air freight and is accompanied by necessary documentation such as mill test reports (MTRs), commercial invoices, packing lists and, upon request, EN10204 Type 3.1 certificates or customer-specific inspection paperwork.
Specification of Inconel 800 800H 800HT Condenser tubes
| Property | Inconel 800 (N08800) | Inconel 800H (N08810) | Inconel 800HT (N08811) |
|---|---|---|---|
| Product Form | Seamless or welded condenser & heat-exchanger tubes | ||
| Standards | ASTM/ASME (common references: B163/B167/B423/B407/B522 for tube & strip items) — verify specific ASTM for your application | ||
| Typical Service Temp | Up to ~700°C (1315°F) | Up to ~850°C (1562°F) for controlled creep resistance | Designed for stabilized high-temperature service up to ~925°C (1700°F) |
| Heat Treatment | Solution annealed | Solution annealed with controlled C for creep strength | Stabilized, higher-temperature temper to improve creep/rupture resistance |
We supply tubing in common condenser sizes and custom dimensions, available in standard factory lengths (for example 6 m and 12 m) or cut-to-length according to project specifications. Typical outer diameters range from small-bore sizes used in compact bundles through to 1" and larger heavy-duty tube sizes; wall thicknesses are offered from thin-walled sections for efficient heat transfer up to heavier walls for higher-pressure or abrasive services.
Chemical Composition of Inconel 800 800H 800HT Condenser tubes
| Element | 800 (N08800) | 800H (N08810) | 800HT (N08811) |
|---|---|---|---|
| Carbon (C) | ≤ 0.10 | 0.05–0.10 (controlled higher C) | 0.05–0.10 (controlled) |
| Chromium (Cr) | 19.0–23.0 | 19.0–23.0 | 19.0–23.0 |
| Nickel (Ni) | 30.0–35.0 | 30.0–35.0 | 30.0–35.0 |
| Iron (Fe) | Balance (~39–46) | Balance | Balance |
| Aluminium (Al) | 0.15–0.60 | 0.15–0.60 | 0.15–0.60 |
| Titanium (Ti) | 0.15–0.60 | 0.15–0.70 | 0.15–0.70 |
| Manganese (Mn) | ≤ 1.0 | ≤ 1.0 | ≤ 1.0 |
| Silicon (Si) | ≤ 1.0 | ≤ 1.0 | ≤ 1.0 |
| Copper (Cu) | ≤ 0.5 | ≤ 0.5 | ≤ 0.5 |
| Others (S,P) | ≤ 0.015 each | ≤ 0.015 each | ≤ 0.015 each |
With a proven track record as a Inconel 800 800H 800HT Condenser tubes exporter in over 30 countries, Sumer Metal Industries ensures global availability, third-party inspection support, and client-specific customization. Our wide export network combined with strict quality standards has made us a preferred choice for SS 800 800H 800HT tubing worldwide.
Specification of Inconel 800 800H 800HT Condenser tubes
| Property | Inconel 800 (N08800) | Inconel 800H (N08810) | Inconel 800HT (N08811) |
|---|---|---|---|
| Product Form | Seamless or welded condenser & heat-exchanger tubes | ||
| Standards | ASTM/ASME (common references: B163/B167/B423/B407/B522 for tube & strip items) — verify specific ASTM for your application | ||
| Typical Service Temp | Up to ~700°C (1315°F) | Up to ~850°C (1562°F) for controlled creep resistance | Designed for stabilized high-temperature service up to ~925°C (1700°F) |
| Heat Treatment | Solution annealed | Solution annealed with controlled C for creep strength | Stabilized, higher-temperature temper to improve creep/rupture resistance |
🏭 Industry & Application
- ✅ SS 800 800H 800HT Condenser Tubes for Medical Industry
- ✅ SS 800 800H 800HT Condenser Tubes for Chemical Processing
- ✅ SS 800 800H 800HT Tubes for Condenser Lines
- ✅ Inconel 800 800H 800HT Condenser tubes for Gas & Liquid Flow
- ✅ SS 800 800H 800HT Tubes for Heat Exchangers
❓ Frequently Asked Questions (FAQs)
1. What is the difference between Inconel 800, 800H and 800HT?
Inconel 800 (UNS N08800) is the base alloy used for elevated-temperature corrosion resistance. 800H (N08810) contains controlled higher carbon for improved creep strength at elevated temperatures. 800HT (N08811) is further processed/stabilized to provide higher temperature strength and superior creep-rupture resistance for prolonged high-temperature exposure.
2. Which grade should I choose for condenser tubes?
Choose 800 for general high-temperature service up to moderate temperatures. Select 800H when the application requires enhanced creep resistance (prolonged service at elevated temperatures). Use 800HT for the highest-temperature service within the 800-series envelope where maximum creep-rupture strength is required.
3. What common standards and specifications apply to these tubes?
Typical references include ASTM/ASME specifications for alloy tubing and strip (confirm the exact sheet/standard for your project). Sumer Metal Industries supplies tubes with material test reports (MTRs) and can provide EN10204 Type 3.1 certification on request. Always confirm the purchaser's specification (ASTM/ASME designation) on the purchase order.
4. What sizes and wall thicknesses are available?
Common condenser ODs range from small-bore sizes (e.g., 6.35 mm / 1/4") up to 25.4 mm (1") and larger. Wall thicknesses typically range from thin-walled (0.5–1.0 mm) for high heat-transfer efficiency to heavier walls (2–3 mm or more) for higher-pressure or abrasive services. Custom sizes and cut-to-length options are available.
